Yealink SIP T21P IP Phone

NOTE: Adapter not included

Yealink's new SIP-T21P takes entry-level IP phones to a level never achieved before. Making full-use of high-quality materials, plus an extra-large 132 x 64-pixel graphical LCD showing a clear 5-line data display, it offers a smoother user experience, much more visual information at a glance, plus HD Voice characteristics. Dual 10/100 Mbps network ports with integrated PoE are ideal for extended network use.

The T21P supports two VoIP account, simple, flexible, and secure installation options, plus support for IPv6, Open VPN, and a redundancy server. It also operates with SRTP/ HTTPS/ TLS, 802.1x. As a very cost-effective and powerful IP solution, the T21P maximizing productivity in both small and large office environments.

View *PDF / Download

Yealink SIP T21P IP Phone

Entry Level IP Phone with 2 Lines & HD voice:

• 2 VoIP accounts, 132x64-pixel graphical LCD
• HD Voice: HD Codec, HD speaker, HD handset
• 2xRJ45 ports, PoE, headset, wall-mountable
• XML/LDAP remote phonebook

1. Phone Features:

• 2 VoIP accounts
• Call hold, mute, DND
• One-touch speed dial, hotline
• Redial, call return, auto-answer
• Call forward, call waiting, call transfer
• Group listening, SMS
• Local 3-way conferencing
• Direct IP call without SIP proxy
• Ring tone selection/import/delete
• Keypad lock, emergency call
• Set date time manually or automatically
• Dial plan, XML Browser, action URL & action URI

2. Network & Security Features:

• SIP v1 (RFC2543), v2 (RFC3261)
• IPv6, Open VPN
• NAT Traverse: STUN mode
• Proxy mode and peer-to-peer SIP link mode
• IP Assignment: Static/DHCP/PPPoE
• HTTP/HTTPS webserver
• Time and date synchronization using SNTP
• UDP/TCP/DNS-SRV(RFC 3263)
• QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS, DSCP
• SRTP for voice
• Transport Layer Security (TLS)
• HTTPS certificate manager
• AES encryption for a configuration file
• Digest authentication using MD5/MD5-sess
• IEEE802.1X

3. Physical Features:

• 2xRJ45 10/100M Ethernet ports
• 31 keys including 4 soft keys
• 4 LEDs: 1xpower, 2xline, 1xmessage
• 1xRJ9 handset port
• 1xRJ9 headset port
• Wall-mountable
• Power adapter: AC 100~240V input and DC 5V/600mA Output
• Power over Ethernet (IEEE 802.3af)
• Power consumption: 1.4-2.6W
• Net weight: 0.81kg
• Dimension: 209mm*188mm*150mm*41mm
• Operating humidity: 10~95%
• Storage temperature: -10~50°C

4. IP PBX System Integration:

• Anonymous call, anonymous call rejection
• Message waiting indicator (MWI)
• Voice mail, call park, call pickup
• Intercom, paging, music on hold
• Call completion, call recording, hot-desking

5. Codecs and Voice Features:

• Full-duplex hands-free speakerphone with AEC
• Codecs: G.722(Wideband), G.711(A/µ), G.723, G.729AB, G.726
• DTMF: In-band, Out-of-band(RFC 2833) and SIP INFO
• VAD, CNG, AEC, PLC, AJB, AGC

6. Management:

• Configuration: browser/phone/auto-provision
• Auto provision via FTP/TFTP/HTTP/HTTPS for mass deploy
• Auto-provision with PnP
• Zero-sp-touch
• Provisioning server redundancy supported
• Reset to factory, reboot
• Package tracing export, system log

Warranty Period: 1 Year

** Warranty does not cover wear and tear, damages arisen from misuse or use not in accordance with product instructions.
