IP Phone VOPTech S4P

Note: This is an IP-Phone, not a conventional telekom phone

S4P/S4G IP Phone is a high-end enterprise desktop phone which comes with intelligent DSS Key-mapping to increase the productivity of enterprise users at a cost-effective price. By using new generation chipset, the S4P/S4G offers unrivalled superb HD Voice Quality, innovative functional richness, friendly user interface, stylish and elegant design. It is definitely able to provide a pleasant and satisfactory end-user experience.

Generic

• 4 SIP Line
• HD Voice
• POE Enabled
• 2.8” color screen
• Handset(HS) / Hands-free(HF) / Headphone(HP) mode (EHSsupportforPlantronicsheadsets)
• Intelligent DSS Keys
• Desktop / Wall-mount installation
• Optional External Power Supply

Call Features

• Call out/answer / reject
• Mute/Unmute(microphone)
• Call Hold/Resume
• Call Waiting
• Intercom
• Caller ID Display
• Speed Dial
• Anonymous Call(Hide Caller ID)
• Call Forwarding(Always/Busy/No Answer)
• Call Transfer(Attended/Unattended)
• Call Parking/Pick-up(depending on server)
• Redial/Auto-Redial
• Do-Not-Disturb(per line/per phone)
• Auto-Answering(per line)
• Voice Message(on server)
• Local 3-way Conference
• Hot Line
• Hot-Desking

Phone Features

• 4 SIP Line
• HD Voice
• POE Enabled
• 2.8” color screen
• Handset(HS) / Hands-free(HF) / Headphone(HP) mode (EHS support for Plantronics headsets)
• Intelligent DSS Keys
• Phonebook (500 entries)
• Remote Phonebook (XML/LDAP)
• Call log (100 entries, in/out/missed)
• Black/White List Call Filtering
• Voice Message Waiting Indication (VMWI)
• Programmable DSS/Soft keys
• Network Time Synchronization
• Action URL / Active URI

Phone Features

• HD Voice Microphone/Speaker (Handset/Hands-free, 0~7KHz Frequency Response)
• Wideband ADC/DAC 16KHz Sampling
• Narrowband CODEC: G.711a/u, G.723.1, G.726-32K, G.729AB
• Wideband CODEC: G.722
• Full-duplex Acoustic Echo Canceller (AEC) – Hands-free Mode, 96ms tail-length
• Voice Activity Detection (VAD) / Comfort Noise Generation (CNG) / Background Noise Estimation (BNE) / Noise Reduction (NR)
• Packet Loss Concealment (PLC)
• Dynamic Adaptive Jitter Buffer up to 300ms
• DTMF: In-band, Out-of-Band – DTMF-Relay(RFC2833) / SIP INFO

Network Features

• 10/100Mbps(S4P), 10/100/1000Mbps(S4G) Ethernet, dual bridged port for PC bypass
• IP Configuration: Static / DHCP / PPPoE
• Network Access Control: 802.1x
• VPN: L2TP (Basic Unencrypted) / OpenVPN
• VLAN
• QoS

Maintenance & Management

• Auto-Provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP PNP/TR069
• Web Management Portal
• Web-based Packet-dump
• Configuration Export / Import
• Phonebook Import/Export
• Firmware Upgrade
• Syslog

Physical Features

• LCD: 2.8 inch (320x240) color-screen
• Keypad: 39 keys, including
• 8 DSS key with tri-color LED
• 4 Soft-keys
• 7 Function keys
• 4 Navigation keys + 1 OK key
• 12 Standard Phone Digits keys
• 2 Volume Control keys, Up/Down
• 1 Hands-free key
• HD Hands-free Speaker (0~7KHz) x1
• HD Hands-free Microphone (0~7KHz) x1
• HD Handset (RJ9) x1
• Standard RJ9 Handset Wire x1
• 1.5M CAT5 Ethernet Cable x1
• RJ9 Phone port x2: Handset x1, Headphone x1
• RJ11 EXT port x1: Extension Module x1
• RJ45 Ethernet Port x2: Network x1 (802.3AF POE Class 2Enabled), PC x1 (Bridged to Network)
• Main Chipset: Broadcom
• DC Power Input: (S4P) 5V / 0.6A, (S4G) 5V / 1A
• Power Consumption: (S4P) Idle –~1.3W, Peak –~4.3W
• (S4G) Idle –~1.7W, Peak –~5.7W
• Working Temperature: 0~40℃
• Working Humidity: 10~65%
• Dual-Functional Back Rack x1: Desktop Stand / Wall-mount
• Color: Black
• Package Dimensions: 260x255x62mm (L x W x H)

Warranty Period : 1 Year
** No Warranty - power cord and adapter
** Warranty does not cover wear and tear, damages arisen from misuse or use not in accordance with product instructions.

We reserve the right to change the feature, function, price, and agreement without prior notice.
